SIEMENS

Siemens 3RT6016-1AF02 SIRIUS 9A 4kW 110V AC Contactor

Siemens 3RT6016-1AF02 SIRIUS 9A 4kW 110V AC Contactor

$12.99 USD
$12.99 USD
Распродажа Продано
Model Number
YingZhou Industrial Automation | Product Information

Siemens 3RT6016-1AF02 SIRIUS AC Power Contactor

9A AC-3 @ 400V | 4kW | 110V AC 50/60Hz | 3-Pole | 1NC
✓ IN STOCK & AVAILABLE TO ORDER  |  Actual Product Photos  |  Exact Model Verified
Specification Verified Product Data
Manufacturer Siemens AG
Catalog Number 3RT6016-1AF02
Product Brand SIRIUS
Product Family 3RT6
Product Type AC Power Contactor
Utilization Category AC-3
Main Poles 3
Main Contacts 3 Normally Open
Auxiliary Contacts 1 Normally Closed (1NC)
Control Coil Voltage 110V AC
Control Coil Frequency 50/60Hz
Rated Current AC-3 @ 400V 9A
Rated Motor Power AC-3 @ 400V 4kW
Frame Size S00
Terminal Connection Screw Connection
Main Input Terminals 1/L1, 3/L2, 5/L3
Main Output Terminals 2/T1, 4/T2, 6/T3
Coil Terminals A1 / A2
Auxiliary NC Terminals 21 / 22
Country of Origin China
EAN / GTIN 4011209880085

Product Overview

The Siemens 3RT6016-1AF02 is a SIRIUS 3RT6 industrial AC power contactor designed for switching suitable motor loads in industrial control systems. The contactor provides a rated operational current of 9A AC-3 at 400V and a rated motor power of 4kW at 400V. The electromagnetic control coil operates at 110V AC, 50/60Hz. It features three normally open main contacts and one normally closed auxiliary contact with terminals 21 and 22. The device belongs to the S00 frame size and uses screw terminal connections. The supplied photographs show both the carton label and the contactor marked 3RT6016-1AF02, with matching catalog numbers. The product is marked Made in China. YINGZHOU offers this model as an in-stock industrial procurement item. Photographic verification confirms the visible model identification but does not establish electrical test results. Buyers should confirm coil supply voltage, load ratings, auxiliary contact requirements and circuit protection coordination before ordering.

Key Product Features

  • SIRIUS 3RT6 Power Contactor — Siemens three-pole industrial AC power contactor.
  • 9A AC-3 Rated Current — Rated operational current of 9A at 400V.
  • 4kW Motor Switching Rating — Rated motor power at 400V under AC-3 utilization.
  • 110V AC Control Coil — 110V AC electromagnetic operating coil at 50/60Hz.
  • Integrated Auxiliary Contact — One normally closed auxiliary contact (21/22).
  • S00 Frame Size — Compact Siemens SIRIUS contactor design.
  • Screw Terminal Connections — Screw-type electrical terminals.
  • Actual Product Photos — Matching Siemens product and carton catalog number 3RT6016-1AF02.
  • In Stock at YINGZHOU — User-confirmed stock availability for exact-model sourcing.

Actual Product Verification

✓ Actual carton and contactor photographs supplied
✓ Carton catalog number: 3RT6016-1AF02
✓ Contactor marking: 3RT6016-1AF02
✓ Both catalog numbers match exactly
✓ Packaging confirms 9A AC-3, 4kW at 400V
✓ Coil rating: 110V AC, 50/60Hz
✓ Auxiliary contact marking: 1NC, terminals 21/22
✓ Siemens SIRIUS product identification
✓ Country of origin marked Made in China
✓ EAN / GTIN: 4011209880085
✓ Electrical function testing not evidenced by photographs

In Stock & Available to Order

Siemens 3RT6016-1AF02 is marked in stock based on YINGZHOU inventory information. Supplied photographs identify matching carton and contactor catalog numbers. The device has a 9A AC-3 rating at 400V, 4kW rated motor power, a 110V AC 50/60Hz control coil and an integrated 1NC auxiliary contact. Contact YINGZHOU for quantity confirmation, electrical condition, shipment arrangements and additional exact-model procurement requirements.

IN STOCK

Siemens 3RT6016-1AF02

Contact us for exact-model verification, multiple units and project sourcing. Confirm the 9A AC-3 rating, 4kW motor power, 110V AC coil and 1NC auxiliary contact before ordering.
