Phoenix Contact QUINT-PS/1AC/24DC/10 2866763 24V 10A 240W Power Supply
Phoenix Contact QUINT-PS/1AC/24DC/10 2866763 24V 10A 240W Power Supply
Не удалось загрузить сведения о доступности самовывоза
Phoenix Contact QUINT-PS/1AC/24DC/10 2866763 Power Supply
| Specification | Verified Product Data |
|---|---|
| Manufacturer | Phoenix Contact |
| Catalog Number | QUINT-PS/1AC/24DC/10 |
| Manufacturer Order Number | 2866763 |
| Product Family | QUINT POWER |
| Product Type | Primary-Switched DIN Rail Power Supply |
| AC Input Phases | 1-Phase |
| Nominal AC Input | 100–240V AC |
| AC Input Voltage Range | 85–264V AC |
| AC Frequency | 45–65 Hz |
| DC Input Voltage Range | 110–350V DC |
| Nominal Output Voltage | 24V DC ±1% |
| Adjustable Output Voltage | 18–29.5V DC |
| Nominal Output Current | 10A |
| Rated Output Power | 240W |
| POWER BOOST Current | 15A at 24V DC, −25°C to +40°C |
| POWER BOOST Output Power | 360W under specified boost conditions |
| SFB Dynamic Current | 60A for 12ms |
| Efficiency at 120V AC | Typically 92% |
| Efficiency at 230V AC | Typically 93.2% |
| Residual Ripple | Less than 50mV P-P |
| Mains Buffering Time | Greater than 36ms |
| Status Monitoring | DC OK LED, Active Signal, Relay Contact |
| Connection Type | Screw Terminals |
| Installation | DIN Rail NS 35 |
| Protection Rating | IP20 |
| Ambient Temperature | −25°C to +70°C, derating above +60°C |
| Derating | 2.5%/K from +60°C to +70°C |
| Dimensions (W × H × D) | 60 × 130 × 125 mm |
| Net Weight | Approx. 1,145 g |
| Packaging Serial Number | 0000725704 |
| Packaging Date | 2025-10-09 |
| Packaging GTIN | 4046356113793 |
| Country of Origin | Thailand (Packaging) |
| Recommended for New Projects | QUINT4-PS/1AC/24DC/10, Item 2904601 |
Product Overview
The Phoenix Contact QUINT-PS/1AC/24DC/10, manufacturer order number 2866763, is a QUINT POWER primary-switched industrial power supply designed for DIN rail installation in compatible industrial control systems. It accepts a single-phase AC nominal input of 100–240V, with an AC operating range of 85–264V at 45–65 Hz. The device delivers a 24V DC nominal output at 10A, providing 240W rated power, with an adjustable output range from 18V to 29.5V DC, subject to the manufacturer's power limits. Its POWER BOOST feature supports 15A at 24V DC within the specified −25°C to +40°C operating conditions. Selective Fuse Breaking (SFB) technology delivers a dynamic current of 60A for 12ms to help operate compatible protective circuit breakers. The device features typical efficiency of 93.2% at 230V AC, an output ripple below 50mV P-P, and mains buffering exceeding 36ms under the manufacturer's specified conditions. DC OK status indication, active signals and a floating relay contact support preventive system monitoring. The metal housing measures 60 × 130 × 125 mm, provides IP20 protection, uses screw terminals, and is designed for DIN rail mounting. The supplied actual photographs show the Phoenix Contact packaging label identifying the exact model QUINT-PS/1AC/24DC/10, order number 2866763, and manufacture in Thailand. The power supply itself has not been photographed or functionally tested in the provided evidence. Phoenix Contact recommends the newer QUINT4-PS/1AC/24DC/10, item 2904601, for new projects. Please confirm the exact unit, input voltage, required load capacity and installation requirements before ordering.
Key Product Features
- 24V DC / 10A Output — Reliable nominal 240W power for compatible industrial control loads.
- Single-Phase AC Input — 100–240V AC nominal, with an operating range of 85–264V AC.
- Adjustable DC Voltage — 18–29.5V DC adjustment for suitable control systems.
- 15A POWER BOOST — Increased output capability under specified operating conditions.
- SFB Technology — 60A dynamic current for 12ms supports selective circuit breaker tripping.
- High Operating Efficiency — Typically 93.2% at 230V AC.
- Preventive Monitoring — DC OK LED, active signal and floating relay contact.
- DIN Rail Installation — Compact metal enclosure with screw terminal connections.
- Industrial Temperature Range — −25°C to +70°C with specified derating.
- Short-Circuit Protection — Manufacturer-specified output short-circuit protection.
- Actual Packaging Verification — Photographed packaging identifies the exact catalog and order numbers.
Actual Product Verification
In Stock & Available to Order
Phoenix Contact QUINT-PS/1AC/24DC/10 (2866763) is marked in stock based on YINGZHOU inventory information. Original packaging photographs are available to confirm the exact catalog and order numbers. This QUINT POWER single-phase DIN rail power supply provides a 24V DC / 10A / 240W nominal output, 100–240V AC nominal input, and the manufacturer's POWER BOOST and SFB current reserves under their specified conditions. The physical device nameplate and functional condition still require confirmation. For replacement power supplies, industrial maintenance and multiple-unit procurement, please verify the exact model, load requirements, installation clearances, accessories and dispatch arrangements before ordering.
Phoenix Contact QUINT-PS/1AC/24DC/10
Contact us for exact-model verification, multiple units and project sourcing. Confirm the 100–240V single-phase AC input, 24V DC output, 10A nominal load, required wiring and installation requirements before ordering.
Request Bulk PricingLooking for other Phoenix Contact industrial automation products?
