| Order Code (Model) |
6ES7214-1AH50-0XB0 |
| Product Family |
SIMATIC S7-1200 Controller Compact Mainframe |
| Hardware Architecture Type |
CPU 1214C DC / DC / DC Platform Configuration |
| Digital Inputs (DI) Count |
14 Points High-Sensitivity 24V DC Sinking/Sourcing |
| Digital Outputs (DO) Type |
10 Points High-Speed Responsive NPN/PNP Transistor Array |
| Analog Inputs (AI) Channels |
2 Channels Integrated Voltage Signals (0 to 10V DC) |
| Onboard Communication |
1x RJ45 Ethernet Networking Terminal (PROFINET Enabled) |
| Operating Supply Input |
24 V DC Rated Circuit Power Connection Bounds |
Performance Overview
The Siemens 6ES7214-1AH50-0XB0 is an industrial-tier premium compact programmable logic controller (PLC) main processing mainframe meticulously engineered within the flagship SIMATIC S7-1200 modular hardware architecture. Formulated specifically to conduct real-time sequential task loops, advanced motion tracking paths, and synchronized data grid exchanges, this high-performance CPU 1214C module manages 24 integrated digital I/O points alongside differential analog inputs flawlessly under typical 24V DC system supplies. The state-of-the-art layout features an native onboard PROFINET interface to interact with remote instrumentation frameworks, plant networks, and HMI units straight without requiring external communication expander modules. Complete with 4 high-frequency pulse counting channels, rich logical workspace memories, and fully integrated TIA Portal vectorized engineering pathways, it drives complex automated plant cells with absolute system consistency.
📋 Critical Application Check
-
Industry: High-Accuracy Electronic Component Sorters, Multi-Axis Motion Positioning Systems, Advanced Packaging Conveyance Loops, Custom Material Handling Feeders, Decentralized Smart Infrastructure Nodes.
-
TIA Portal Vector Synergy: Unified modular environment optimizes configuration tracking parameters, saving diagnostic turnaround periods across dense multi-drop logic setups effortlessly.
-
Transistor Output Speed Advantage: Embedded solid-state transistor switching boundaries support high-frequency execution tracks, guiding stepper or servo motor drives directly with zero contact wear loops.
Siemens SIMATIC S7 Automation Systems Integration:
