| Order Code (Model) |
OS-1/4-B |
| Festo Part Number |
6682 |
| Valve Function |
3/2-Way OR Logic Shuttle Circuit |
| Pneumatic Connection Port |
G1/4 Female Parallel Thread Matrix |
| Actuation Mechanism Layout |
Pneumatic Air Signal Driven Internal Shuttle |
| Standard Nominal Flow Rate |
Optimized High-Flow Internal Air Path Guide |
| Operating Pressure Range |
1 ~ 10 bar Versatile High Pressure Logic Setup |
| Housing Core Profile |
Die-Cast Anodized Alloy Frame Armor |
Performance Overview
The Festo OS-1/4-B (Part Number: 6682) is an industrial-tier premium 3/2-way pneumatic OR logic shuttle control valve engineered specifically to serve as a high-reliability fluid gateway inside rugged factory automation grids. Machined with a robust standard G1/4 parallel porting layout, this highly responsive directional component handles working parameters from 1 up to 10 bar safely. The internal logic gate is optimized with an ultra-low friction shuttle spool assembly to capture shifting pressure inputs fluidly, routing compressed air to the output terminal with absolute zero-delay response boundaries. Built using a high-density anodized alloy housing block paired with premium inner seals, it coordinates dual-input signaling arrays with total consistency.
📋 Critical Application Check
-
Industry: Dual-Station Machine Safety Operations, Remote Cylinder Interlock Switches, Pneumatic Automation Emergency Backups, Branch Circuit Signal Aggregations, Mechanical Control Gateways.
-
Zero-Electrical Spark Safety: Bypasses electrical wire requirements entirely, delivering a 100% explosion-proof physical mechanical link perfect for volatile painting or woodworking dust loops.
-
Dynamic Shuttle Response: Built-in low-inertia seal ring structures permit instant switching action between inputs, safeguarding overall tool uptime and system tracking accuracy.
