FESTO ESNU-16-50-P-A 19265 ISO Pneumatic Cylinder 16mm Bore 50mm Stroke Single Acting Spring Return

FESTO ESNU-16-50-P-A 19265 ISO Pneumatic Cylinder 16mm Bore 50mm Stroke Single Acting Spring Return

$34.99 USD
$34.99 USD
Sale Sold out
Model Number
YingZhou Industrial Automation | Product Information

FESTO ESNU-16-50-P-A ISO Standard Pneumatic Cylinder

16mm Bore | 50mm Stroke | Single Acting | Spring Return | Part No. 19265
✓ IN STOCK & AVAILABLE TO ORDER  |  Actual Product Photos  |  Packaging Model Verified
Specification Verified Product Data
Manufacturer FESTO / Festo SE & Co. KG
Catalog Number ESNU-16-50-P-A
Part Number 19265
Product Family ESNU
Product Type ISO Standard Pneumatic Cylinder
Standard ISO 6432 / CETOP RP 52 P
Piston Diameter 16 mm
Stroke 50 mm
Operating Mode Single-acting, pushing
Return Mechanism Spring return
Cushioning Elastic cushioning rings/plates at both ends
Position Detection Via proximity switch
Piston Rod Thread M6
Piston Rod End Male thread
Operating Pressure 1.2–10 bar
Pneumatic Connection M5
Operating Medium Compressed air per ISO 8573-1:2010 [7:4:4]
Ambient Temperature −20°C to +80°C
Corrosion Resistance Class CRC 2
Theoretical Force at 6 bar — Advance 106.5 N
Impact Energy at End Position 0.15 J
Mounting Position Any
Photographed Packaging Origin Made in China

Product Overview

The FESTO ESNU-16-50-P-A (part number 19265) is a single-acting ISO 6432 standard pneumatic cylinder with a 16 mm piston diameter and 50 mm stroke. It provides pneumatically driven extension with spring return and features elastic cushioning rings or plates at both ends. The cylinder operates at 1.2–10 bar, uses an M5 pneumatic connection and has an M6 male piston rod thread. The supplied actual packaging photograph confirms the exact model and part number; functionality has not been independently tested.

Key Product Features

  • ISO 6432 Pneumatic Cylinder — FESTO ESNU standardized cylinder.
  • 16 mm Piston Bore — Manufacturer-confirmed piston diameter.
  • 50 mm Stroke — Specified linear travel distance.
  • Single-Acting Operation — Pneumatic extension with spring-assisted return.
  • Elastic Cushioning — Cushioning rings or plates at both ends.
  • 1.2–10 bar Operating Pressure — Verified pressure specification.
  • M5 Port and M6 Rod Thread — Manufacturer-confirmed interfaces.

Actual Product Verification

✓ Actual packaged-product photograph supplied
✓ Packaging model: ESNU-16-50-P-A
✓ Manufacturer part number: 19265
✓ Label identifies FESTO and Made in China
✓ Exact model and part number match the requested product
✓ Cylinder operating condition and function have not been independently tested

In Stock & Available to Order

FESTO ESNU-16-50-P-A, part number 19265, is marked in stock based on supplied inventory information. Actual packaging photography is available. Please confirm order quantity, mounting requirements and dispatch arrangements before placing an order.

IN STOCK

FESTO ESNU-16-50-P-A

Contact us for exact-model confirmation, bulk orders and project sourcing. Verify the 16mm bore, 50mm stroke, single-acting spring-return configuration and mounting requirements before ordering.
