Allen-Bradley 1769-ECR Compact I/O Right End Cap

Compact I/O | Right End Cap | Bus Terminator | 1769 System Accessory
✓ IN STOCK & AVAILABLE TO ORDER  |  Actual Packaging Photos  |  Exact Catalog Number 1769-ECR
Specification Verified Product Data
Manufacturer Allen-Bradley / Rockwell Automation
Catalog Number 1769-ECR
Product Family Compact I/O / Bulletin 1769
Product Type Right End Cap / Bus Terminator
Accessory Category Compact I/O System Accessory
Installation Position Right End of Compatible 1769 I/O Bank
Primary Function Terminate / Complete Communication Bus
Bus Interface 1769 Compact I/O Backplane
Current Draw @ 5.1V DC 5 mA
Current Draw @ 24V DC 0 mA
Height 118 mm
Maximum Width in Drawing 32 mm
Depth 85 mm
Narrow Profile Dimension 18 mm
Mounting Arrangement End of Compatible 1769 System Assembly
System Mounting DIN Rail or Panel, per System Instructions
Enclosure Type Open-Type
Operating Temperature 0°C to +60°C
Maximum Surrounding Air Temperature 60°C
North American Temperature Code T3C
UK / ATEX / IECEx Temperature Code T4
Conformal Coating Variant 1769-ECRK (Separate Catalog Number)
Manufacturer Lifecycle Active Mature

Product Overview

The Allen-Bradley 1769-ECR is a Compact I/O right end cap and communication bus terminator manufactured by Rockwell Automation. Designed for compatible Bulletin 1769 Compact I/O systems, it is installed at the right-hand end of a controller or I/O bank where a right-end terminator is required. The end cap completes the communication bus connection and covers the exposed end of the 1769 assembly. It is a system termination accessory, not an independent power supply, controller or digital I/O module. The 1769-ECR has a manufacturer-specified 5mA current draw at 5.1V DC and 0mA at 24V DC, with an operating temperature range of 0°C to +60°C. The manufacturer's installation drawing shows a height of 118mm, depth of 85mm and maximum width dimension of 32mm. The supplied actual packaging photograph identifies catalog number 1769-ECR, Series A. The product-unit nameplate is not shown. Confirm the controller architecture, end-cap position and applicable 1769 system requirements before ordering.

Key Product Features

  • Compact I/O Right End Cap — Allen-Bradley Bulletin 1769 system termination accessory.
  • Communication Bus Termination — Completes the right end of the compatible 1769 communication bus.
  • Right-Hand Installation — Designed for the right end of supported Compact I/O bank arrangements.
  • Low Backplane Current Draw — Rated at 5mA at 5.1V DC and 0mA at 24V DC.
  • Compact Mechanical Design — 118mm height, 85mm depth and 32mm maximum width in the installation drawing.
  • Industrial Temperature Rating — Supports ambient operation from 0°C to +60°C.
  • CompactLogix System Integration — Used with compatible 1769 I/O arrangements according to Rockwell Automation system instructions.

Actual Product Verification

✓ Actual product packaging photograph supplied
✓ Packaging catalog number 1769-ECR clearly visible
✓ Packaging label identifies Series A
✓ Product description marked RIGHT END CAP / TERMINATOR
✓ Firmware marked N/A
✓ Manufacturing date 2022/06/21 visible
✓ Packaging label marked PRODUCT OF MALAYSIA
✓ Product-unit nameplate and physical condition are not confirmed by the supplied photograph
✓ Confirm the exact end cap, system arrangement and included accessories before ordering

In Stock & Available to Order

Allen-Bradley 1769-ECR is marked in stock based on the supplied inventory information. Please reconfirm order quantity and dispatch date before checkout. The supplied photograph verifies the packaging label, but the product-unit identification, physical condition and included accessories have not been independently verified. Buyers should confirm whether a right-end terminator is required for their 1769 Compact I/O system before ordering.

IN STOCK

Allen-Bradley 1769-ECR

Order online or contact us for multiple units and project sourcing. Please confirm the exact 1769 system configuration, right-end bus termination requirements and installation arrangement.
