| Order Code (Model) |
HMIGXU3500 |
| Brand Manufacturer |
Schneider Electric Group |
| Product Range Classification |
Magelis GXU Basic Optimized Human-Machine Interfaces |
| Display Size & Type |
7.0 Inch WVGA High-Contrast TFT 16:9 Widescreen LCD |
| Resolution & Depth |
800 x 480 Pixels running at 65,536 Dynamic Colors |
| Embedded Network Links |
1x RJ45 Ethernet 10/100M + 1x Integrated RS-485 Serial Channel |
| Expansion Peripheral Gates |
1x USB Type A Terminal Block + 1x USB Mini-B Sync Node |
| Operating Input Power |
24 V DC Standardized System Power Interface Bounds |
Performance Overview
The Schneider Electric HMIGXU3500 is an industrial-tier premium touch panel human-machine interface (HMI) meticulously engineered within the flagship Magelis GXU basic visualization hardware framework. Purpose-built to execute reliable high-frequency plant data monitoring and field operational command entries for standardized industrial automation grids, this entry-level interactive device governs master machinery systems fluidly with operational consistency. The state-of-the-art layout integrates a sharp 7.0" WVGA 16:9 Widescreen True Color TFT LCD display backed by an adaptive high-resolution resistive touchscreen, letting machinery crews track asset parameters straight through clear, high-contrast dynamic widescreen layouts. Complete with integrated 10/100 Base-T Ethernet network ports, standard isolated RS-485 industrial serial architecture, and dedicated USB memory allocation block hubs, it drives modern automated factories with absolute performance consistency.
📋 Critical Application Check
-
Industry: Standardized Materials Packaging Lines, Textile Machinery Matrices, Food Production Conveyor Sorters, Assembly Line Dashboard Overviews.
-
Network Coordination: Native onboard Ethernet pipelines coupled with integrated RS-485 channels execute master PLC registry polling smoothly without deploying standalone terminal hubs.
-
Enclosure Protection: Robust physical molding resists daily industrial dust accumulations and minor vibration impacts, extending tactile durability in standard manufacturing resonance environments.
