OMRON

Omron PYFZ-14-E 14-Pin Relay Socket 4-Pole 6A 250VAC DIN Rail Mount

Omron PYFZ-14-E 14-Pin Relay Socket 4-Pole 6A 250VAC DIN Rail Mount

정가 $3.99 USD
정가 할인가 $3.99 USD
할인 품절
Model Number
YingZhou Industrial Automation | Product Information

Omron PYFZ-14-E 14-Pin Relay Socket

14-Pin | 4-Pole | 6A per Pole | 250VAC | DIN Rail Mount
✓ IN STOCK & AVAILABLE TO ORDER  |  Actual Product Photos  |  Model Verified
Specification Verified Product Data
Manufacturer OMRON Corporation
Catalog Number PYFZ-14-E
Product Family PYFZ / PYF Common Sockets
Product Type Industrial Relay Socket
Pin Configuration 14-Pin, 4-Pole
Connection Front Connecting
Terminal Type Screw Terminal, M3
Mounting Method DIN Rail / Screw Mounting
Safety Structure Finger Protection
Maximum Carry Current 6A per Pole
Total Current Limit 20A when all 4 poles are used
Rated Voltage 250VAC
Dielectric Strength 2,250VAC for 1 minute
Insulation Resistance 1,000 MOhm Min. at 500VDC
Ambient Temperature -55 to +70°C
Ambient Humidity 5-85% RH
Approximate Weight 50 g
Product Dimensions Approx. 72 x 29.5 x 31 mm
Country of Origin China (Photographed Unit)

Product Overview

The Omron PYFZ-14-E is a 14-pin, four-pole industrial relay socket designed for compatible plug-in relays. This front-connecting socket features screw terminals, a finger-protection structure, and DIN rail or screw-mounting options for use in industrial electrical control panels.

The socket is rated for 6A maximum continuous current per pole at 250VAC, with a combined maximum of 20A when all four poles carry current. It provides a convenient mounting and wiring interface for compatible relay installations, supporting relay replacement without rewiring each individual connection.

Important: PYFZ-14-E is a relay socket, not a relay. A compatible relay must be selected separately. Check the relay pin configuration, mounting requirements and electrical ratings before ordering.

Key Product Features

  • 14-Pin Socket Configuration — Designed for compatible four-pole plug-in relays.
  • 6A per Pole — Continuous carry-current rating for industrial relay connections.
  • 250VAC Rating — Socket electrical rating for compatible applications.
  • 20A Total Current Limit — Maximum combined current when all four poles are energized.
  • DIN Rail or Screw Mounting — Flexible mounting options for electrical panels.
  • Screw Terminal Wiring — Front-access terminal connections for control cabinet installation.
  • Finger-Protection Structure — Protective terminal design for industrial wiring applications.
  • Wide Ambient Temperature Range — Rated for -55 to +70°C.
  • Industrial Maintenance — Suitable for replacement of the same socket model in compatible relay systems.

Actual Product Verification

✓ Actual product and packaging photographs supplied
✓ Carton catalog number: PYFZ-14-E
✓ Socket marking: 6A maximum per pole
✓ Socket marking: 20A total, 250VAC
✓ Packaging lot number: 03Y25C3
✓ Product marking includes matching lot number
✓ Carton label quantity: 50 pieces
✓ Product origin marking: Made in China
Photographs document the photographed stock batch. Individual items are quoted and priced separately unless a full-carton quantity is agreed.

In Stock & Available to Order

Omron PYFZ-14-E relay sockets are marked IN STOCK based on the supplied inventory information. YINGZHOU supports industrial spare-parts procurement, single-model orders and bulk quantity quotations. Please confirm the required quantity, compatible relay model, and destination before ordering.

IN STOCK

Omron PYFZ-14-E Relay Socket

Need one socket or a bulk quantity? Contact YINGZHOU for exact-model sourcing and quantity pricing. Confirm the required relay configuration before purchase.

Request Bulk Pricing
