FESTO ADN-20-15-A-P-A 536236 Compact Pneumatic Cylinder 20mm Bore 15mm Stroke Double Acting ISO 21287

FESTO ADN-20-15-A-P-A 536236 Compact Pneumatic Cylinder 20mm Bore 15mm Stroke Double Acting ISO 21287

$18.99 USD
$18.99 USD
In offerta Esaurito
Model Number
YingZhou Industrial Automation | Product Information

FESTO ADN-20-15-A-P-A 536236 Compact Pneumatic Cylinder

20mm Bore | 15mm Stroke | Double Acting | 0.6–10 Bar | ISO 21287
✓ IN STOCK & AVAILABLE TO ORDER  |  Actual Product Photos  |  Exact Model Confirmed on Nameplate
Specification Verified Product Data
Manufacturer Festo SE & Co. KG
Catalog Number ADN-20-15-A-P-A
Manufacturer Part Number 536236
Product Family ADN
Product Type Compact Pneumatic Cylinder
Piston Diameter 20 mm
Stroke 15 mm
Mode of Operation Double-Acting
Operating Pressure 0.06–1 MPa / 0.6–10 bar
Conforms to Standard ISO 21287
Piston Rod Thread M8
Piston Rod End External Thread
Piston Rod Configuration Single Rod End
Cushioning Elastic Cushioning Rings/Pads at Both Ends
Position Sensing For Proximity Sensor
Pneumatic Connection M5
Mounting Position Any
Mounting Options Through-Hole / Internal Thread / Accessories
Operating Medium Compressed Air per ISO 8573-1:2010 [7:4:4]
Ambient Temperature -20°C to +80°C
Theoretical Force at 6 Bar, Advancing 188 N
Theoretical Force at 6 Bar, Retracting 141 N
Impact Energy at End Positions 0.2 J
Moving Mass 41 g
Product Weight 161 g
Corrosion Resistance Class CRC 2
Piston Rod Material High-Alloy Steel
Cylinder Barrel Material Smooth-Anodized Wrought Aluminum Alloy
Cover Material Anodized Wrought Aluminum Alloy
Seal Material TPE-U (PUR)
Country of Origin (Photo) China

Product Overview

The FESTO ADN-20-15-A-P-A, manufacturer part number 536236, is a compact double-acting pneumatic cylinder designed in accordance with ISO 21287. It features a 20 mm piston diameter and a 15 mm stroke for controlled linear pneumatic movement. The cylinder operates within a pressure range of 0.6 to 10 bar and features elastic cushioning rings/pads at both ends. It is equipped with an M8 external piston rod thread, M5 pneumatic connections, and provisions for position sensing using suitable proximity sensors. At 6 bar, the manufacturer specifies a theoretical advancing force of 188 N and a theoretical retracting force of 141 N. The cylinder is rated for ambient temperatures from -20°C to +80°C and incorporates a smooth-anodized aluminum alloy barrel with a high-alloy steel piston rod. Confirm the required mounting arrangement, air supply conditions and application load before installation.

Key Product Features

  • FESTO ADN Compact Cylinder — Manufacturer part number 536236, conforming to ISO 21287.
  • 20 mm Bore and 15 mm Stroke — Compact dimensions for controlled linear pneumatic movement.
  • Double-Acting Operation — Pneumatic extension and retraction with a single-ended piston rod.
  • 0.6–10 Bar Operating Pressure — Manufacturer-specified operating range for suitable compressed-air systems.
  • Elastic End-Position Cushioning — Integrated cushioning rings/pads at both cylinder ends.
  • Proximity Sensor Position Sensing — Designed for operation with suitable position-sensing accessories.
  • Durable Compact Construction — Anodized aluminum alloy cylinder barrel, high-alloy steel piston rod and M5 pneumatic ports.

Actual Product Verification

✓ Actual packaged FESTO cylinder photograph supplied
✓ Cylinder nameplate identifies model ADN-20-15-A-P-A
✓ Manufacturer material number: 536236
✓ Maximum pressure marking: 1 MPa (145 psi)
✓ Production/series marking visible: 03-2025:58
✓ Manufacturer marking: FESTO
✓ Labelled country of origin: China
✓ Requested catalog number and photographed nameplate match
✓ Cylinder supplied in protective plastic packaging as photographed

In Stock & Available to Order

FESTO ADN-20-15-A-P-A (536236) is marked in stock based on the supplied inventory information. Actual cylinder nameplate photography is available for exact-model confirmation. This compact double-acting pneumatic cylinder features a 20 mm bore, 15 mm stroke, elastic end-position cushioning and an operating pressure range of 0.6–10 bar. Please confirm the required piston rod thread, M5 pneumatic connection, mounting method, application load and dispatch arrangements before ordering.

IN STOCK

FESTO ADN-20-15-A-P-A 536236

Contact us for exact-model verification, multiple units and pneumatic cylinder sourcing. Please confirm the 20 mm bore, 15 mm stroke, operating pressure and installation requirements before ordering.
