Schneider Electric SH31404P02F2000 Lexium SH3 PacDrive 3 AC Servo Motor
140mm | 33.4N·m Stall | 4000rpm Max | SinCos Multiturn | Holding Brake
| Specification |
Product Data |
| Brand |
Schneider Electric |
| Exact Model |
SH31404P02F2000 |
| Series |
Lexium SH3 / PacDrive 3 |
| Device Short Name |
SH3.....P |
| Product Type |
AC Servo Motor |
| Motor Phases |
Three Phase |
| Motor Frame / Flange Size |
140 mm |
| Rated Voltage Range |
115–480 V, Three Phase |
| Maximum Mechanical Speed |
4000 rpm |
| Continuous Stall Torque |
33.4 N·m |
| Peak Stall Torque |
131.9 N·m |
| Continuous Stall Current |
21.3 A |
| Maximum Current (Irms) |
95.6 A |
| Continuous Power |
4040 W |
| Nominal Output Power at 115V |
2370 W |
| Nominal Output Power at 230V |
4130 W |
| Nominal Output Power at 400V |
5060 W |
| Nominal Output Power at 480V |
4190 W |
| Nominal Torque at 115V |
30.2 N·m |
| Nominal Torque at 230V |
26.3 N·m |
| Nominal Torque at 400V |
16.1 N·m |
| Nominal Torque at 480V |
11.1 N·m |
| Nominal Speed at 115V |
750 rpm |
| Nominal Speed at 230V |
1500 rpm |
| Nominal Speed at 400V |
3000 rpm |
| Nominal Speed at 480V |
3600 rpm |
| Shaft Type |
Smooth Shaft |
| Shaft Diameter |
24 mm |
| Shaft Length |
50 mm |
| Encoder Type |
Absolute Multiturn SinCos Hiperface |
| Encoder Resolution |
128 Periods |
| Holding Brake |
Integrated |
| Holding Brake Torque |
36 N·m |
| Connector Orientation |
90° Angled |
| Motor Connector |
M40 |
| Encoder Connector |
M23 |
| Motor Protection Rating |
IP65, EN/IEC 60034-5 |
| Shaft Bushing Without Shaft Seal |
IP54, EN/IEC 60034-5 |
| Cooling Type |
Natural Convection |
| Mounting Support |
International Standard Flange |
| Motor Length |
420.5 mm |
| Centring Collar Diameter |
130 mm |
| Mounting Hole Quantity |
4 |
| Mounting Hole Diameter |
11 mm |
| Mounting Hole Circle Diameter |
165 mm |
| Torque Constant |
1.57 N·m/A at 120°C |
| Back EMF Constant |
104 V/krpm at 20°C |
| Rotor Inertia |
29.2 kg·cm² |
| Stator Resistance |
0.28 Ohm |
| Stator Inductance |
5.945 mH |
| Maximum Axial Force |
300 N |
| Maximum Radial Force at 1000rpm |
2660 N |
| Maximum Radial Force at 2000rpm |
2110 N |
| Maximum Radial Force at 3000rpm |
1840 N |
| Net Weight |
27.8 kg (Historical Manufacturer Datasheet) |
| GTIN / EAN |
3606485298177 |
| Country of Origin |
Germany |
| Manufacturer Package Quantity |
1 Piece |
Product Overview
The Schneider Electric SH31404P02F2000
is a three-phase AC servo motor from the
Lexium SH3 range,
designed for the PacDrive 3
motion control platform.
Featuring a 140mm motor flange,
it delivers 33.4N·m continuous stall torque
and up to 131.9N·m peak stall torque
under manufacturer-specified conditions.
The motor supports a
maximum mechanical speed of 4000rpm,
with nominal torque, speed and output power
dependent on operating voltage.
Its configuration includes a
smooth output shaft,
an absolute multiturn SinCos Hiperface encoder,
an integrated 36N·m holding brake
and 90-degree angled motor and feedback connectors.
The motor is designed for integration with
a correctly selected Schneider Electric
servo drive and compatible connection accessories.
This listing is for the servo motor only.
A compatible drive and required cables
must be selected separately.
Key Product Features
-
Lexium SH3 servo motor designed for the PacDrive 3 motion control platform
-
33.4N·m continuous stall torque for manufacturer-specified operating conditions
-
131.9N·m peak stall torque for short-duration peak demand
-
4000rpm maximum mechanical speed with voltage-dependent nominal performance
-
Absolute multiturn SinCos Hiperface encoder with 128-period feedback resolution
-
Integrated 36N·m holding brake for properly designed motor holding applications
-
140mm flange and 24mm smooth shaft with angled M40/M23 connections
-
Natural convection cooling and specified IP54/IP65 protection according to motor section and shaft sealing
Actual Product Verification
✓
Actual Schneider packaging photo
✓
Exact model SH31404P02F2000
visible on the packaging label
✓
Schneider branding, PacDrive marking
and package barcode visible
✓
Verify exact model, motor shaft,
encoder, holding brake and
compatible servo drive before ordering
Available to Order — Estimated Delivery 6–8 Weeks
Schneider Electric SH31404P02F2000
is available to order
with an estimated delivery time of
6–8 weeks.
An actual Schneider packaging photograph
is provided for exact model verification.
This Lexium SH3 AC servo motor
features a 140mm mounting flange,
33.4N·m continuous stall torque,
4000rpm maximum mechanical speed,
an absolute multiturn encoder
and an integrated holding brake.
This listing is for the motor only.
Please confirm the exact model,
shaft configuration, feedback system,
holding brake requirements,
compatible servo drive and quantity
before purchasing.
Contact our team for delivery confirmation
and international shipping arrangements.
ESTIMATED DELIVERY 6–8 WEEKS
Schneider Electric SH31404P02F2000
Contact us to confirm lead time, order quantity and project pricing.
Request Project Pricing
