Schneider Electric ATS480D22Y Altivar ATS480 Soft Starter
22A Normal Duty | 208–690V AC | 3-Phase | 11kW at 400V
| Specification |
Product Data |
| Brand |
Schneider Electric |
| Exact Model |
ATS480D22Y |
| Series |
Altivar Soft Starter ATS480 |
| Product Type |
Industrial Soft Starter |
| Product Destination |
Asynchronous Motors |
| Network Phases |
3-Phase |
| Power Supply Voltage |
208–690V AC, -15% / +10% |
| Control Supply Voltage |
110–230V AC, 50/60Hz |
| Rated Current - Normal Duty |
22A at 40°C |
| Rated Current - Heavy Duty |
17A at 40°C |
| Motor Power @ 230V |
5.5kW Normal / 4kW Heavy, In-Line |
| Motor Power @ 400V |
11kW Normal / 7.5kW Heavy, In-Line |
| Motor Power @ 500V |
11kW Normal / 9kW Heavy, In-Line |
| Motor Power @ 690V |
18.5kW Normal / 15kW Heavy, In-Line |
| Starting Technology |
Torque Control System (TCS) |
| Motor Protection |
Integrated Motor Overload Protection |
| Communication Protocol |
Modbus Serial (RS-485) |
| Optional Communication |
Modbus TCP, EtherNet/IP, PROFINET, PROFIBUS DP, CANopen via Optional Modules |
| Bypass Function |
External Bypass Control Supported |
| Protection Rating |
IP20 |
| Dimensions (W × H × D) |
160 × 275 × 203 mm |
| Net Weight |
4.9 kg |
Product Overview
The Schneider Electric ATS480D22Y is an
industrial soft starter from the
Altivar Soft Starter ATS480 series,
designed for three-phase asynchronous motors.
It provides a 22A normal-duty rating
and a 17A heavy-duty rating at 40°C,
with a 208–690V AC main power supply.
At 400V, the ATS480D22Y supports
11kW normal-duty or
7.5kW heavy-duty motor applications
with in-line connection.
Its torque-control technology, integrated motor
protection and built-in Modbus serial communication
support industrial motor starting and stopping.
Key Product Features
-
22A normal-duty rated current at 40°C
-
17A heavy-duty rated current at 40°C
-
208–690V AC three-phase power supply
-
11kW at 400V normal-duty motor rating, in-line
-
110–230V AC control power supply
-
Torque Control System for motor starting and stopping
-
Built-in Modbus Serial communication
- Integrated Motor Overload Protection
-
External Bypass Control supported
Actual Product Verification
✓
Actual packaging photo
✓
Packaging model label visible
✓
ATS480D22Y and electrical ratings shown
✓
Verify exact unit model/nameplate before ordering
In Stock & Ready to Order
Schneider Electric ATS480D22Y is
currently in stock according to our inventory
information.
An actual packaging photograph showing the
exact model and electrical rating is provided.
Please confirm the required quantity, exact
model configuration and shipping details
before ordering.
IN STOCK
Schneider Electric ATS480D22Y
Order online or contact us for project and quantity pricing.
Request Project Pricing
